Road contractors across the Philippines face daily pressure to deliver durable lane markings on tight schedules. Painted lines fade within months under tropical sun and heavy rain. Imported thermoplastic striping equipment costs too much and parts take weeks to arrive. Many Filipino road crews need a reliable thermoplastic line striping machine that handles 100-450mm line widths, runs on battery power, and applies consistent glass bead coverage. YG Machinery’s thermoplastic striping equipment series solves these problems with adjustable spreading systems and 48V lithium batteries. The YG-360S and YG-380S models deliver 1-8km/h marking speed. 【WhatsApp/WeChat/Skype/Phone】+86 159 3715 2330
Get Thermoplastic Line Striping Machine Price
Thermoplastic Line Striping Machine Parameters
| Model | YG-360S | YG-380S |
| Thermoplastic Tank | synchronous clutch spreading, equipped with a speed-adjustable gear shifting device, single/double spreading can be selected according to needs, 50-200mm | synchronous clutch spreading, equipped with a speed-adjustable gear shifting device, single/double spreading can be selected according to needs, 50-200mm |
| Glass Bead Container | 10kg/box | 10kg/box |
| Adjustable glass bead spreader | Ensure the machine is moving in a straight line or turning freely on the curved road | Ensure the machine is moving in a straight line or turning freely on a curved road |
| Rear Wheel Directional Device | 100kg, double stainless steel heating insulation barrels, plug-in manual mixer devices, and removable devices | Ensure the machine moving in a straight line or turning freely on a curved road |
| Brake | Using a drum brake, you can adjust the brake tension | Using a drum brake, you can adjust the brake tension |
| Marking width | Standard 150mm marking bucket 100mm、150mm、200mm、250mm、300mm、400mm、450mm (at customers’ option) | Standard 150mm marking bucket 100mm、150mm、200mm、250mm、300mm、400mm、450mm (at customers’ option) |
| Battery Capacity | 15AH | 15AH |
| Battery Voltage | 48V lithium battery | 48V lithium battery |
| Driver Speed | 1-8km/hour | 1-8km/hour |
| Working Duration | The machine can mark road lines24 hours after charging the battery, 5 hours | Ensure the machine is moving in a straight line or turning freely on a curved road |
| Dimensions | 1210X970X1070mm | 1200X970X1100mm |
| Net weight | 130kg | 100kg, double stainless steel heating insulation |
Get Thermoplastic Line Striping Machine Price
Case Study One: Philippines – Highway Lane Marking Project
Client Background
A road contractor in Luzon secured a contract to mark 45 kilometers of national highway with thermoplastic lane lines. The project required center lines, edge lines, and lane dividers in 150mm and 200mm widths. Work had to proceed during night closures with minimal traffic disruption.
Client Challenge
The contractor’s old painted-line equipment produced markings that faded within 4 months. The client needed a thermoplastic line striping machine that could apply consistent 150mm lines at walking speed. Night work required reliable battery operation without generator noise. The project timeline allowed only 6 weeks for all 45 kilometers.
YG Solution
YG supplied the YG-360S thermoplastic line striping machine with 48V lithium battery and 1-8km/h driver speed. The 15AH battery supports 5 hours of continuous marking after full charge. The adjustable spreading system delivers 50-200mm line widths with synchronous clutch control. The 10kg glass bead container ensures even bead coverage for night visibility. The drum brake allows precise speed control on downhill sections.
Client Feedback and Results
“The YG-360S marked 8 kilometers per night shift with consistent line width. The thermoplastic lines reflect better than our old paint, even after heavy rain.” The project supervisor confirmed the contractor finished all 45 kilometers in 5 weeks, one week ahead of schedule. The highway authority approved the markings without rework.
Get Thermoplastic Line Striping Machine Price
Case Study Two: Vietnam – Urban Road Marking Contract
Client Background
A Vietnamese road marking contractor in Ho Chi Minh City handles municipal road projects. The company won a contract for 120,000 square meters of thermoplastic markings across 15 city streets, including curved intersections and pedestrian crossings.
Client Challenge
The contractor needed a compact thermoplastic line striping machine for narrow city streets. Curved roads required precise steering without drifting. The machine had to fit on standard transport trucks and maneuver around parked vehicles. The client also needed adjustable marking widths from 100mm to 450mm for different road types.
YG Solution
YG recommended the YG-380S thermoplastic line striping machine with 130kg net weight and 1210X970X1070mm dimensions. The rear wheel directional device keeps the machine on straight lines or allows free turning on curves. The 100-450mm marking width options handle center lines, edge lines, and crosswalks. The 48V lithium battery runs 5 hours per charge for full night shifts. The double stainless steel heating insulation barrels maintain thermoplastic temperature.
Client Feedback and Results
“The YG-380S handles curved intersections without drifting. We switch between 150mm and 300mm widths in minutes.” The project manager confirmed the contractor completed 120,000 square meters in 10 weeks. The city approved the markings for reflectivity and durability. The contractor ordered a second machine for their next municipal contract.
Request Thermoplastic Striping Machine Pricing
Application Areas
Beyond highway and urban road marking, YG’s thermoplastic line striping machine is widely applicable across multiple sectors:
Airport Runway Marking – Apply durable centerlines, threshold bars, and taxiway markings. The thermoplastic striping equipment handles high-visibility requirements with glass bead reinforcement.
Parking Lot and Warehouse Floor Marking – Mark parking bays, traffic lanes, and safety zones. The machine’s adjustable 100-450mm widths suit various layout requirements.
Factory and Industrial Floor Marking – Apply lane dividers, pedestrian walkways, and hazard zones. The 48V battery operation allows indoor use without exhaust concerns.
Thermoplastic Line Striping Machine for Sale – YG Machinery
YG Machinery offers reliable thermoplastic line striping machine for sale for Philippine, Vietnamese, and worldwide road marking projects. Besides, we also produce cold paint spray line stripers and thermoplastic melting kettles. This means you can equip your entire road marking crew from one supplier. Contact YG Machinery for the latest road machine price and project consultation. Our team provides transparent pricing, operator training, and global shipping. 【WhatsApp/WeChat/Skype/Phone】+86 159 3715 2330
